| Series-5 Focuser (Stackable with Series-5 Rotator) |
- The Series-5 focuser is a large capacity focuser for use with Alt/Az, or equatorially mounted systems.
- The focuser is capable of lifting 40 lbs (18 kg) with a travel range of 0.6-inches (15,200 microns).
- The Series-5 focuser can be stacked with the Series-5 rotator for a complete focusing rotator solution (combined 2.78″ of occupied backfocus).
- Occupies only 1.675” of backfocus.
- 464.4283 encoder counts per micron
- Controlled via PWI4 software for autofocusing and optional field de-rotation (if using an Alt/Az mounted system).
- Requires the Series-5 Controller.
- Compatible with the DeltaRho 350 and RC700 telescopes.
| $3,500.00 | |
| Series-5 Rotator (Stackable with Series-5 Focuser) |
- The Series-5 rotator is a large-capacity rotator for use with Alt/Az, or equatorially mounted systems.
- The rotator is capable of lifting 40 lbs (18 kg) with a travel range of 680 degrees between mechanical hardstops.
- The Series-5 rotator can be stacked with the Series-5 focuser for a complete focusing rotator solution (combined 2.78″ of occupied back focus).
- Occupies only 1.105” of back focus.
- Controlled via PWI4 software for autofocusing and optional field de-rotation (if using an Alt/Az mounted system).
- Requires the Series-5 Controller.
- Compatible with DeltaRho and RC700 telescopes.
- 3,637,531 encoder counts per rotation (10104.25 counts per degree, 2.806 counts per arcsecond).
- *Series-5 rotator shown stacked with the focuser is sold separately.
| $3,500.00 | |
| IRF90 – Integrated Rotating Focuser |
- The IRF90 is a large capacity Integrated Focuser and Rotator for use with Alt/Az, or equatorially mounted systems.
- Occupies 3.5″ of backfocus with the focuser fully racked in, and 4.7″ when fully racked out.
- The Focuser is capable of lifting 40 lbs (18 kg) with a range of 30mm (30000 microns/1.2″).
- The Rotator has a 90mm aperture with a range of 365 degrees with hard stops to eliminate any chance of cord wrap.
- IRF90 is controlled via PWI4 software for autofocusing and optional field de-rotation (if using an Alt/Az mounted system).
| $5,200.00 | |
